SN74LS37N, NAND Gate, Quad, 2 Inputs, 14 Pins, DIP, 74LS37

Logic Function: NAND Gate

Logic Family / Base Number: 74LS37

No. of Elements: Quad

Logic Type: NAND Bufer

No. of Inputs: 2Inputs

Output Current: 24mA

Supply Voltage Min: 4.75V

Supply Voltage Max: 5.25V

Logic Case Style: DIP

Product Range: 74LS37

No. of Pins: 14Pins

Logic IC Family: 74LS

Logic IC Base Number: 7437

Schmitt Trigger Input: Without Schmitt Trigger Iput

Operating Temperature Min: 0°C

Operating Temperature Max: 70°C

ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala.
