TSA5511T, PLL Frequency Synthesizer, 1.3 GHz Bidirectional I2C, PDSO-16, NXP

FEATURES

• Complete 1.3 GHz single chip system

• Low power 5 V, 35 mA

• I2C-bus programming

• In-lock flag

• Varicap drive disable

• Low radiation

• Address selection for Picture-In-Picture (PIP), DBS tuner (3 addresses)

• Analog-to-digital converter

• 8 bus controlled ports (5 for TSA5511T), 4 current limited outputs (1 for TSA5511T), 4 open collector outputs (bi-directional)

• Power-down flag



APPLICATIONS

• TV tuners

• VCR Tuners
